A legend turns 50!

161 BECOMES 161PX - PROXIMA

With outstanding qualitative properties, our dust- and waterproof light fitting 161 has earned a legendary reputation over half a century. Since its introduction in 1972, we have continued to develop and improve it. Then as now, it impresses with its unreachable quality Made in Germany. And the almost unlimted options to customize it leave nearly nothing to be desired.
With the new 161PX PROXIMA, we have now perfectly engineered the legendary 161 to LED technology and set a new benchmark. A luminaire you can always rely on.
You will not find a better dust- and waterproof light fitting for rough industrial environments.



Extremely robust and perfectly adapted



The Highlights

Extremely robust

  • High-impact resistant housing, wall thickness 1.8 mm
  • Diffuser with high mechanical stability, wall thickness 2.0 mm
  • Robust closure clips and safety locks

Highly flexible

  • FastFix quick-mounting system with variable mounting distances
  • Variable cable entry thanks to additional entries at the front and in the centre of the top of the enclosure
  • Prepared for 3-pole loop in/loop out wiring on the front side

Efficient, sustainable and future-proof

  • Luminous efficacy up to 163 lm/W = high energy cost savings
  • Service life L80 > 70,000 hours
  • All components can be replaced on site
  • Use of LED modules according to Zhaga standard

PROXIMA Icons

The right solution for every challenge

The PROXIMA is a true multi-talent and thus ideal for industrial use with its diverse requirements.
Countless modifications show what is possible. We have compiled a small selection for you here:

Light colour
  • 3,000K; 4,000K; 6,500K
  • Colour rendering Ra > 90 (light colour 940)
  • Coloured LEDs for signalling applications and special areas (e.g. potato storage)
  • Amber LEDs (light colour 518) e.g. for insect-friendly lighting in outdoor areas
Lighting control/Light management
  • DALI control DIM (DIMD)
  • Dimming function "Corridor Mode" (DIMC or DIMC Z30)
  • HF sensor (SENS)
  • Variably adjustable luminous flux (VARIO)
  • Radio-controlled lighting management system (LIMAS Air)
  • Wired light management system (LIMAS Line)
  • Wired light management system with central monitoring of single-battery emergency luminaires (LIMAS Line PRO)
Temperature range
  • High temperatures up to +70°C
  • Low temperatures down to -40°C
  • Wide temperature ranges from -40°C to +70°C
Special area of application
  • Unprotected outdoor areas (AUS)
  • Food processing areas (IFS)
  • Areas with intensive cleaning and desinfection (LM)
  • Areas stressed with harmful gases (RESISTANT series ER/HR)
  • Areas with high vibrations (RF)
Emergency lighting
  • Single-battery version with automatic self-test (MA)
  • Single-battery version for high ambient temperatures up to +50°C (H50 MA)
  • Single-battery version with DALI emergency unit for central monitoring (MA-Z)
  • For connection to central power supply (ZB)
Futher modifications
  • Protection class II (SKII)
  • FastConnect plug connection system (FC)
  • Stainless steel closure clips and safety locks (KE)
  • Polycarbonate cover (PC)
  • Through-wiring up to 7x2.5mm² etc.



We will also find solutions for further extraordinary applications. We will be pleased to advise you!

161PX PROXIMA

161PX PROXIMA

The next generation for rough industrial use: extremely robust, highly efficient, durable and always perfectly adapted.
161PX PROXIMA VARIO

161PX PROXIMA VARIO

The robust multi-talent is of course also available as a VARIO version with variably adjustable luminous flux.
PROXIMA Flyer

PROXIMA Flyer

More information on the new 161PX PROXIMA luminaire series

Please note: article data for the above modifications can be found within the respective product family 161PX or 161PX VARIO.
