High-temperature, low-temperature and wide-temperature luminaires
Extreme temperatures place high demands on the thermal management of LED luminaires. Design and component selection must ensure that the luminaires function perfectly under these extreme conditions and achieve the specified luminous flux and efficiency values in practical operation. Making honest and transparent statements about these properties contributes significantly to high customer satisfaction. With luminaires from SCHUCH, you are on the safe side.
In addition to the solo performers for high or low ambient temperatures, the wide-temperature light fittings occupy a special position in our range.
Wide-temperature light fittings are all-rounders that can be used at both low and high temperatures. As they cover a wide temperature range, they are the ideal solution for areas with widely varying temperatures, such as climatic chambers, test benches in the automotive industry and material containers, but also for regions/climate zones with large temperature fluctuations.
Here you will find product solutions for temperatures from - 40 °C to + 70 °C. Due to the special requirements in explosion protection, consultation is required for individual solutions in the high temperature range.
Articles – Zone 1/21
| Type | Temperature [°C] | Service life at max. temp. [h] | Luminous flux [lm] | Efficiency [lm/W] | |
| Zone 1/21 | |||||
| ExeLED 1 | |||||
| e865 … H60/65 | + 60/65 | L80 > 100.000 | 2.200 - 6.000 | up to 156 | To the series |
| e865 … H70 | + 70 | Consulting required | Enquire article | ||
| e865 … T40 | − 40 | L80 > 100.000 | 2.200 - 6.000 | up to 156 | To the series |
| ExeLed 1 N | |||||
| e864 … H50/55 (single-battery emergency light) | +50/55 | L80 > 100.000 | 2.200 - 6.300 | up to 158 | To the series |
| e840 … H50/55 | + 50/55 | L80 > 100.000 | 2.000 - 8.300 | up to 154 | To the series |
| e840 … H65 | + 65 | Consulting required | Enquire article | ||
| e855 … H60 | + 60 | L80 > 100.000 | 500 - 2.050 | up to 114 | To the series |
| e856 … H55 (single-battery emergency light) | + 55 | L80 > 100.000 | 500 - 2.050 | up to 108 | To the series |
| e821 … H55 | + 55 | L80 > 100.000 | 2.100 - 11.500 | up to 155 | To the series |
| e821 … H65 | + 65 | Consulting required | Enquire article | ||
| e8820 … H55 | + 55 | L80 > 100.000 | 10.300 - 23.700 | up to 136 | To the series |
| e8820 … T40 | − 40 | L80 > 100.000 | 13.500 - 31.600 | up to 126 | To the series |
| e8825 … H55 | + 55 | L80 > 100.000 | 10.300 - 23.700 | up to 136 | To the series |
| e8825 … T40 | − 40 | L80 > 100.000 | 13.500 - 31.600 | up to 126 | To the series |
Articles – Zone 2/22
| Type | Temperature [°C] | Service life at max. temp. [h] | Luminous flux [lm] | Efficiency [lm/W] | |
| Zone 2/22 | |||||
| ExeLED 2 | |||||
| nD866 … H60/65 | + 60/65 | L80 > 100.000 | 4.300 - 6.300 | up to 164 | To the series |
| nD866 … T40 | − 40 | L80 > 100.000 | 4.300 - 6.300 | up to 164 | To the series |
| ExeLED 2 N | |||||
| nD867 … H55 (single-battery emergency light) | + 55 | L80 > 100.000 | 2.200 - 6.300 | up to 158 | To the series |
| nD8611 … H60 | + 60 | Consulting required | Enquire article | ||
| ExDUEVO | |||||
| nD8301/8302 … H50/60 | + 55/60 | L70 > 90.000 | 10.800 - 21.600 | up to 161 | To the series |
| ExFOCO L | |||||
| nD8700 … H55 | + 55 | Consulting required | Enquire article | ||
| ExFOCO XL | |||||
| nD8800 … H50 | + 50 | Consulting required | Enquire article | ||
For temperatures from - 40 °C to + 90 °C, we offer a wide range of products for a wide variety of industrial applications. In special cases, luminaires with external ballasts can be the solution. We will be happy to advise you.
Articles
| Type | Temperature [°C] | Service life at max. temp. [h] | Luminous flux [lm] | Efficiency [lm/W] | |
| DUEVO | |||||
| 3301/3302 … H50/60 | + 50/60 | L70 > 100.000 | 10.800 - 40.400 | up to 161 | To the series |
| 3301/3302 … H70 | + 70 | L70 > 100.000 | 10.800 - 21.600 | up to 161 | To the series |
| 3301 … H80 | + 80 | L70 > 100.000 | 10.800 | 161 | To the series |
| 3301/3302 … H90 OV | + 90 | Consulting required | Enquire article | ||
| 3301/3302 … T40 | – 40 | L70 > 100.000 | up to 161 | To the series | |
| TRIANO disc | |||||
| 3410 … H50 | + 50 | L80 > 80.000 | 10.000 | 154 | To the series |
| 3420/3430 … H45 | + 45 | L80 > 80.000 | 18.000 - 30.000 | up to 161 | To the series |
| TRIANO | |||||
| 3401/3402 … H50/60 | + 50/60 | L80 > 80.000 | 13.500 - 20.000 | up to 163 | To the series |
| 3402 … H70 | + 70 | L80 > 80.000 | 13.500 - 20.000 | up to 163 | To the series |
| 3402 … T40 | – 40 | L80 > 80.000 | 13.500 - 20.000 | up to 163 | To the series |
| TRIANO L | |||||
| 3403 … H50/60 | + 50/60 | L80 > 80.000 | 27.000 - 39.500 | up to 163 | To the series |
| 3403 … H70 | + 70 | L80 > 80.000 | 27.000 | 163 | To the series |
| 3403 … T40 | − 40 | L80 > 80.000 | 27.000 - 39.500 | up to 163 | To the series |
| TRIANO XL | |||||
| 3405 … H50/60 | + 50 | L70 > 100.000 | 32.000 - 60.000 | up to 160 | To the series |
| 3405 … H70 | + 70 | L70 > 100.000 | 32.000 | 160 | To the series |
| 3405 … T40 | − 40 | L70 > 100.000 | 32.000 - 60.000 | up to 160 | To the series |
Our portfolio of dust- /waterproof luminaires not only includes high and low temperature luminaires from - 40 °C to + 80 °C, but also wide-temperature luminaires. These all-rounders are for applications where both low and high temperatures can occur, such as in climatic chambers, test stands in the automotive industry or in regions with high temperature fluctuations. We also offer solutions that cover temperature ranges from - 40 °C to max. + 80 °C. Translated with DeepL.com (free version)
Articles
| Type | Temperature [°C] | Service life at max. temp. [h] | Luminous flux [lm] | Efficiency [lm/W] | |
| PROXIMA | |||||
| 161PX …H50 | + 50 | L70 > 100.000 | 1.300 - 7.400 | up to 163 | To the series |
| 161PX … T40 | − 40 | L70 > 100.000 | 2.400 - 14.300 | up to 163 | To the series |
| 161PX … T40 H60/70 | − 40 up to + 60/70 | L70 > 100.000 | 2.400 - 6.100 | up to 163 | To the series |
| 161PX … H50 MA (single-battery emergency light) | + 50 | L70 > 100.000 | 1.300 - 6.100 | up to 146 | To the series |
| With the exception of the emergency light, the comparable versions of the predecessor series 161 are also available for existing systems. | |||||
| 163 G2 … H50 | + 50 | L70 > 100.000 | 2.500 - 6.100 | up to 153 | To the series |
| 163 G2 … T40 | – 40 | L70 > 100.000 | 2.300 - 6.000 | up to 159 | To the series |
| LUXANO | |||||
| 167 G2 … H50 | + 50 | L70 > 100.000 | 3.700 - 6.000 | up to 154 | To the series |
| 167 G2 … T40 | – 40 | L70 > 100.000 | 3.700 - 10.700 | up to 154 | To the series |
| 167 G2 … T40 H50 | – 40 up to + 50 | L70 > 100.000 | 3.700 - 6.000 | up to 154 | To the series |
| 144 … H50 | + 50 | L70 > 100.000 | 2.300 - 6.600 | up to 164 | To the series |
| 144 … T40 | – 40 | L70 > 100.000 | 2.300 - 6.600 | up to 164 | To the series |
| 144 … T40 H60 | − 40 up to + 60 | L70 > 100.000 | 2.300 - 6.600 | up to 164 | To the series |
| PRIMO XR | |||||
| 107 … H50 | + 50 | L70 > 100.000 | 2.300 - 6.300 | up to 155 | To the series |
| 107 … T40 | – 40 | L70 > 100.000 | 2.300 - 6.300 | up to 155 | To the series |
| 107 … T40 H50 | − 40 up to + 50 | L70 > 100.000 | 2.300 - 6.300 | up to 155 | To the series |
| TUBEO | |||||
| 110 … H50 | + 50 | L70 > 100.000 | 2.400 - 6.200 | up to 164 | To the series |
| 110 … T40 | − 40 | L70 > 100.000 | 2.400 - 6.200 | up to 164 | To the series |
| 110 … T40 H50 | − 40 up to + 50 | L70 > 100.000 | 2.400 - 6.200 | up to 164 | To the series |
| 3611 … H50 | + 50 | L80 > 50.000 | 700 | 110 | To the series |
| 3611 … T40 | – 40 | L80 > 50.000 | 650 - 1.200 | up to 118 | To the series |
| 3611 … T40 H50 | – 40 up to + 50 | L80 > 50.000 | 700 | 110 | To the series |
| 131 L07 T40 | − 40 | L80 > 50.000 | 800 | 98 | To the series |
| 185 … T40 | − 40 | L70 > 100.000 | 3.100 - 12.300 | up to 146 | To the series |
| 185 … T40 H60/70/80 | – 40 up to + 60/70/80 | L70 > 100.000 | 3.100 - 9.300 | up to 146 | To the series |
The versions listed here are our standard solutions. Detailed information can be found under the respective series. If you have additional requirements and wishes, further products are available on request. Contact us, we will find a solution to your problem.
